ATEX & IECEx: Zoning, Equipment Selection and the Explosion Protection Document

Where flammable gases, vapours, mists or combustible dusts are present in normal operation or as a result of foreseeable releases, the equipment and operating regime fall under explosive-atmosphere regulation. In the EU the two directives are ATEX 2014/34/EU (equipment manufacturers and authorised representatives) and ATEX 1999/92/EC (operators / employers). The global parallel is the IECEx Scheme based on IEC 60079 series standards, accepted by many non-EU regulators. The US uses NEC Article 500 (Class/Division) and the harmonised Class/Zone in Article 505. This guide focuses on ATEX and IECEx, which dominate specialty chemicals operations.

Start free trial Free trial, no credit card, onboard in days, not months.

Zoning — gas/vapour vs dust

ATEX 1999/92/EC requires the operator to classify hazardous areas by probability and duration of explosive atmosphere. Gas/vapour zones: Zone 0 (present continuously or for long periods), Zone 1 (likely in normal operation), Zone 2 (not likely, and if it occurs only briefly). Combustible dust zones: Zone 20 / 21 / 22 with parallel logic. Zoning drives equipment category and operating discipline; under-zoning is the most expensive ATEX mistake because it allows equipment that is not adequate for the actual atmosphere.

Equipment categories under ATEX 2014/34/EU

Equipment categories map to zones with a one-up margin: Category 1 for Zone 0/20, Category 2 for Zone 1/21, Category 3 for Zone 2/22. Equipment carries the Ex marking with category, gas/dust group (IIA/IIB/IIC for gas; IIIA/IIIB/IIIC for dust), temperature class (T1–T6 for gas; surface temperature in °C for dust), and protection concept (d flameproof, e increased safety, i intrinsic safety, p pressurised, etc.). Manufacturer's EU Declaration of Conformity and the type-examination certificate from a Notified Body underpin the marking.

The Explosion Protection Document (EPD)

ATEX 1999/92/EC Article 8 requires every operator with potentially explosive atmospheres to produce and maintain an Explosion Protection Document covering: substance flammability data, zoning, equipment selection rationale, ignition-source assessment (mechanical, electrical, electrostatic, hot surfaces, exothermic reactions), organisational and technical measures, training, and emergency procedures. The EPD must be reviewed on any process change. National regulators (e.g. BG RCI in Germany, HSE in UK) sample EPDs in routine inspections.

Ignition source control and electrostatic discharge

ISO 80079-36/37 and IEC 60079-32-1 catalogue ignition sources: hot surfaces, flames, mechanical sparks, electrical equipment, stray currents, lightning, RF, ultrasonic, optical, ionising radiation, exothermic reactions including self-ignition, adiabatic compression, electrostatic discharges. Powder handling, drum/IBC filling, pneumatic conveying and solvent transfer are recurring ESD risks — minimum ignition energy (MIE) and minimum ignition temperature (MIT) drive bonding/earthing, conductive equipment selection and ventilation requirements.

IECEx, NEC parallels and a 60-day readiness path

IECEx (based on IEC 60079) is the global parallel; equipment certified under IECEx is widely accepted across non-EU jurisdictions and increasingly in EU practice as part of the ATEX evidence trail. NEC Article 500 (Class/Division) remains common in US practice; Article 505 brings the IEC zone system to US installations. A 60-day ATEX readiness path: Days 1–10 zoning audit by area; Days 11–25 equipment register reconciliation against zone; Days 26–40 EPD currency review; Days 41–55 ignition-source register review with ESD walk-down on solvent/powder handling; Days 56–60 training-and-procedure audit (Article 11).

Standards covered in this guide

Each standard, retailer code or assurance scheme referenced above has its own deep-dive page with scope, audit detail and common pitfalls.

Where this lives in V5 Ultimate

The clauses above aren't theoretical — every one maps to a shipped module and an industry profile. Jump to the parts of the product that turn this guide into evidence on a Monday morning.

Modules that do the work

Zoning & EPD

Zone map, ignition-source register, EPD on one spine.

Ex equipment register

Marking, DoC, type-exam certificates, inspection cycles.

MOC → re-zoning

Process change auto-triggers EPD review.

Industries this hits hardest

Specialty & Industrial Chemicals

Frequently asked

Is IECEx equivalent to ATEX?

Closely aligned but not interchangeable for EU market access. ATEX 2014/34/EU is the EU legal vehicle and requires EU DoC and (for higher categories) Notified Body involvement; IECEx is a conformity assessment scheme based on IEC 60079 standards. Equipment can hold both certifications and most major manufacturers do; the marking and documentation must satisfy whichever regulator applies in the use country.

Do we need ATEX equipment in a Zone 2 area?

Yes — Zone 2 requires at least Category 3 equipment (or Category 2 / Category 1 as a higher-margin alternative). 'General industrial' equipment without Ex marking is not permitted in any classified zone. The exception is equipment that cannot become an ignition source by inherent design (e.g. simple mechanical equipment without electrical parts and below MIT) but the rationale must be documented in the EPD.

Does dust really need its own zoning?

Yes. Combustible dust explosions (sugar, flour, metal powders, plastic powders, organic chemicals) have caused some of the worst industrial incidents on record. Zones 20/21/22 use the same probability logic as gas zones but the engineering controls differ — housekeeping, deflagration venting, suppression and isolation become primary alongside equipment selection.

How does the OSHA combustible dust standard compare?

OSHA does not have a single federal combustible dust standard; it uses the General Duty Clause backed by NFPA 652 / 654 / 484 / 61 / 664 (industry-specific) and recently NFPA 660 (consolidated). The substantive engineering (zoning equivalent, equipment selection, housekeeping, deflagration venting) tracks closely to ATEX dust-zone practice, though the regulatory mechanism is different.
